Aerial Order Picker
Self Propelled Order Picker 136kg Cap 3m height
1. Carrying one person with weight less than 136kg capacity up to 3.1m height. 2. Lifting goods less than 90kgs load tray capacity from 41.3" to 149.5" in height 3. Cargo with weight less than 240 lbs load deck for powered cargo shelf, 200 lbs for chassis shelf. 4. Electric move, Electric lift, 2 × 12 V/150 Ah battery, free maintenance. 5. 110-220 V Build-in charger solution, 8 hrs charging time 6. Turning radius: 55’’ , 15% Grade-ability 7. Wheel type: Non-marking, Anti-Skid Solid Rubber 8. Drive motor: 0.8-1.2 KW, Driving speed: from 1 to 3.36 mph with choice. 9. Product weight: 1180 lbs (520kgs) 10. Ground clearance: 57mm
⭐ New Generation | Self Propelled
SP50 Self Propelled Electric Order Picker
Model: SP50 | 136kg Operator Capacity | 3.1m Platform Height. SP50 is a compact, self-propelled electric order picker engineered for efficient warehouse picking operations. With 5.1m working height, intelligent driving system, and durable aluminum alloy mast, it delivers precision, safety, and productivity in narrow aisle environments.
⚡ Electric 24V DC🔄 Self-Propelled🛡️ Intelligent Steering Return🔋 300 Lifts / 10km drive📦 Multi-Shelf Capacity
✔ ISO9001 & CE Certified | OEM & Customization Available | Global Shipping
Why Choose SP50 Order Picker
🏗️
High-Strength Aluminum Alloy Mast
Aircraft-grade aluminum alloy elevating mechanism ensures exceptional rigidity, minimal oscillation, and smooth lifting/lowering for maximum stability at height.
🔄
Active Front Steering + Rear Bridge Drive
Active front steering combined with rear bridge drive structure effectively prevents loss of direction, maintaining superior walking performance even on uneven ground.
🧠
Intelligent Driving Assistance
Steering wheel automatically returns to center when released, reducing operator actions and enabling faster, more intuitive control with less fatigue.
🎛️
Ergonomic Proportional Control
Proportional valve handles provide precise, effortless driving and lifting control—ideal for long shifts and high-frequency operations.
💡
LED Auxiliary Work Lights
Built-in LED lights provide supplementary illumination for low-light work environments and nighttime warehouse operations.
🧰
Removable Tool Box
Convenient detachable tool box for storing common tools and accessories, enhancing on-the-job efficiency and organization.
Complete Technical Specifications
Model | SP50 | |
|---|---|---|
📐 DIMENSIONS | ||
Max. Platform Height | 3100mm (3.1m) | |
Max. Working Height | 5100mm (5.1m) | |
Platform Size (L×W) | 696mm × 564mm | |
Platform Entry Height | 350mm | |
Occupants (Platform) | 1 person | |
Stowed Length × Width × Height | 1595mm × 750mm × 1528mm | |
Machine Weight (Reference) | 520kg | |
⚖️ LOAD CAPACITIES | ||
Operator Compartment Capacity | 136kg (300 lbs) | |
Powered Cargo Shelf Capacity | 90kg | |
Ground Cargo Shelf Capacity | 115kg | |
🚀 PERFORMANCE | ||
Moving Method | Self Propelled (Electric Drive) | |
Drive Speed (Level 1/2/3) | 5.4 km/h / 3.2 km/h / 1.6 km/h | |
Driving System | Proportional Control | |
Platform Cycle Performance | Raise: 18 sec / Lower: 20 sec | |
Max. Steering Angle | 80° | |
Turning Radius (Outside / Inside) | 1.8m / ~0m | |
Climb Ability | 15% grade | |
Max. Allowed Wind Speed | 12.5 m/s | |
Rated Oil Pressure | 10 MPa | |
Maximum Horizontal Lateral Force | 200 Newtons | |
Tires | Non-marking, Anti-Skid Solid Rubber | |
Battery Durable Time | 300 lifting cycles or 10km driving distance | |
🔋 POWER SOURCE | ||
Power Supply | DC 24V | |
Power Input | 0.8 – 1.2 kW | |
Battery | 12V / 150Ah × 2 pieces (24V system) | |
Recharge Power Supply | 220V AC or 110V AC (Dual Voltage Compatible) | |
* Specifications are subject to change without notice. Contact Outstrip for latest updates.
